| . . | YY12B00154F1 | [1] | ARM | KOBGROUP |
| A1. | YY12B01249F1 | [1] | LINK | KOBASSY, BUCKET |
| A1-1. | NSS | [1] | NOT SOLD SEPARAT | CONLINK, BUCKET |
| A1-2. | LP12B01031P1 | [2] | BUSHING | KOB |
| A1-3. | LP12B01036P1 | [2] | BUSHING | KOB |
| A2. | YY12B01074P1 | [1] | LINK | KOB |
| A3. | YW12B01034P1 | [1] | LINK | KOB |
| A4. | YY12B01242P1 | [2] | PIN | KOB |
| A5. | LP12B01028P1 | [1] | PIN | KOB Superseded by part number: YX12B01042P1 |
| A6. | LP12B01029P1 | [1] | PIN | KOB Superseded by part number: YX12B01042P1 |
| A7. | HS18C14115G2 | [2] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOBM14x2.0x150mm |
| A8. | ZN18C14011 | [4] | NUT | KOBM14x2.0mm |
| A9. | 2445R220D2 | [4] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| A10. | 2445R138D3 | [6] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| A11. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| A12. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A13. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| A14. | YW12B01025P1 | [6] | SHIM,62mm ID x 100mm OD x 3mm Thk | KOBID 62 x OD 100 x Th 3.0mm |
| A15. | B16T0442D56 | [6] | SHIM,62mm ID x 100mm OD x 0.5mm Thk | KOBID 62 x OD 100 x Th 0.5mm |
| A16. | B16T0442D43 | [6] | SHIM,62mm ID x 100mm OD x 0.9mm Thk | KOBID 62 x OD 100 x Th 0.9mm |
| A17. | B16T0442D27 | [6] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOBID 62 x OD 100 x Th 1.2mm |
| A18. | B16T0442D19 | [6] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOBID 62 x OD 100 x Th 1.6mm |
| A19. | 2444R1117D175 | [1] | HOSE,6.40mm ID x 1750mm L | KOB |
| A20. | 2444R1117D145 | [1] | HOSE,6.40mm ID x 1450mm L | KOB1450mm Long |
| A21. | ZH32Z04000 | [1] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| A22. | 2432R225D4 | [2] | CLIP | KOB Superseded by part number: ZC46X11009 |
| A23. | 2432R226D3 | [2] | CLIP | KOBClamp, Double -- ID 10 x 48mm Long Superseded by part number: ZC48X10009 |
| A24. | ZN18C06005 | [4] | NUT | KOBM06x1.0mm |
| A25. | ZW16X06000 | [4] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| A26. | ZW26X06000 | [4] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| . . | YY12B00179F1 | [1] | ARM | KOBASSY, LONG |
| B1. | NSS | [1] | NOT SOLD SEPARAT | CONARM, LONG |
| B1-2. | YY12B01003P1 | [1] | PLATE | KOB |
| B1-3. | YY12B01004P1 | [1] | PLATE | KOB |
| B1-4. | YY12B01011P1 | [2] | PLATE | KOB |
| B1-5. | YY12B01012P1 | [1] | PLATE | KOB |
| B1-6. | YY12B01044P1 | [1] | PLATE | KOB |
| B1-7. | 2416T13112 | [1] | BLOCK | KOBTAPPED Superseded by part number: YY12B01319P1 |
| B1-8. | YY12B01285P1 | [1] | BLOCK | KOBTAPPED Superseded by part number: YY12B01320P1 |
| B1-9. | YN43H01051P1 | [2] | BLOCK | KOBTAPPED |
| B2. | LP12B01030P1 | [2] | BUSHING | KOB |
| B3. | YW12B01042P1 | [2] | BUSHING | KOB |
| B4. | YX12B01021P1 | [2] | BUSHING | KOB |
| . . | YY12B00003F2 | [1] | ARM | KOB |
| C1. | LP02B01012P2 | [1] | PIN | KOB |
| C3. | 2418T12645D2 | [1] | PLATE | KOB125 x 261 x Th 9.0mm |
| C4. | ZS18C12020 | [2] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| C5. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBM16x2.0x140mm |
| C6. | ZN18C16013 | [2] | NUT | KOBM16x2.0mm |
| C7. | B16T0442D44 | [3] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| C8. | YN12B01009P1 | [4] | SHIM,3mm Thk | KOB(3.0) |
| C9. | B16T0442D57 | [3] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| C10. | B16T0442D1 | [1] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| C11. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| C12. | YY12B01170P1 | [1] | PIN | KOB |
