纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-051-03[01]) - HYDRAULIC CIRCUIT - PILOT CONTROL LINES WITH LOAD HOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
340 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHJ1402 | [2] | ADAPTER | SUM |
| 2. | 154475A1 | [1] | O-RING | SUM |
| 3. | 152128A1 | [3] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 5. | 161842A1 | [1] | ADAPTER,3/8" - 19 NPT x 1/4" - 19 ORB | SUM |
| 6. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 8. | KRJ4336 | [2] | HYDRAULIC HOSE,9.50 mm ID x 2200.00 mm | SUM |
| 9. | 168025A1 | [2] | HYDRAULIC HOSE,9.50 mm ID x 1950.00 mm | SUM |
| 10. | 159214A1 | [1] | HYDRAULIC HOSE | SUM1200 mm (47-1/4 in) |
| 11. | 159213A1 | [1] | HYDRAULIC HOSE | SUM1150 mm (45-3/8 in) |
| 23. | KHJ1345 | [2] | HYDRAULIC HOSE,9.52 mm ID x 2150.00 mm | SUM |
