纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-055-00[01]) - HYDRAULIC CIRCUIT- PILOT CONTROL LINES WITHOUT LOAD HOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
289 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 70. | KUJ0320 | [1] | BRACKET | SUM |
| 70A. | KUJ0370 | [2] | BRACKET | SUM Superseded by part number: KUJ0452 |
| 71. | 166352A1 | [7] | BOLT | SUM |
| 72. | KTJ2108 | [1] | COVER | SUM |
| 73. | 166052A1 | [4] | BOLT | SUM Superseded by part number: 11106231 |
| 74. | KUJ0101 | [1] | VALVE, CUSHION | SUM |
| 77. | KHJ1460 | [1] | HYDRAULIC HOSE | SUM |
| 78. | KBJ2349 | [1] | HOSE | SUMHose |
| 80. | KTJ1639 | [1] | HOSE | SUM |
| 88. | KTJ2109 | [1] | BRACKET | SUM |
| 90. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 91. | 154475A1 | [1] | O-RING | SUM |
| 94. | 164107A1 | [1] | TEE,3/8" ORB x 3/8" - 19 NPT x 3/8" - 19 NPT | SUM |
| 97. | 159063A1 | [1] | HOSE | SUM |
| 98. | KRJ4970 | [1] | HOSE | SUM |
| 117. | 159064A1 | [1] | HOSE | SUM |
| 118. | KRJ4762 | [1] | HOSE | SUM |
| 119. | MPJ5480 | [1] | HOSE | SUM |
| 151. | 159036A1 | [1] | CLAMP | SUM |
| 152. | 166350A1 | [2] | BOLT | SUM |
| 165. | 150071A1 | [1] | MOUNTING CLIP | SUM |
