| 1. |
84147955
|
[1] |
FRAME
|
ZED
|
| 1. |
87698664
|
[1] |
FRAME
|
ZED
|
| 2. |
87699043
|
[1] |
SUPPORT
|
ZED
|
| 3. |
87699046
|
[1] |
SUPPORT
|
ZED
|
| 4. |
87717614
|
[2] |
PLATE
|
ZED
|
| 5. |
84165058
|
[1] |
PROFILE
|
ZED
|
| 6. |
84175953
|
[1] |
ROD
|
ZED
|
| 7. |
447598
|
[1] |
EYEBOLT,M16
|
BER
|
| 8. |
362528
|
[1] |
CLEVIS PIN,M16 x 55mm OAL
|
ZED
|
| 9. |
370539
|
[1] |
COTTER PIN,4.4mm x 52.8mm L
|
ZED
|
| 10. |
87622404
|
[4] |
BUSHING
|
ZED
|
| 11. |
84175934
|
[2] |
SLAT
|
ZED
|
| 12. |
9837933
|
[3] |
SPACER,17mm ID x 25.4mm OD x 12.5mm L
|
ZED
|
| 13. |
86595832
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 14. |
140048
|
[2] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 15. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 16. |
140046
|
[5] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 17. |
300389
|
[4] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
, Serial Range: -C839 Superseded by part number: 628-12035
|
| 17. |
86629541
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
, Start Serial: D840
|
| 18. |
9706685
|
[5] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 19. |
84069248
|
[12] |
RIVET,Pop, 4.8mm OD x 20.7mm L
|
ZED
|
| 20. |
543043
|
[8] |
WASHER,13mm ID x 35mm OD x 2.5mm Thk
|
NH
|
| 21. |
86508581
|
[1] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
| 22. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 23. |
43128
|
[2] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 24. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 25. |
84211993
|
[2] |
PLATE
|
ZED
|
| 26. |
14441321
|
[4] |
HEX SOC SCREW,M6 x 16mm, Cl 8.8
|
NH
Superseded by part number: 84814920
|
| 27. |
84212194
|
[8] |
SHIM
|
ZED
|
| 28. |
84213193
|
[1] |
SUPPORT
|
ZED
|
| 29. |
84213189
|
[1] |
SUPPORT
|
ZED
|
| 30. |
84205753
|
[1] |
ROLLER,108mm OD x 1069mm L
|
ZED
|
| 30. |
84206214
|
[1] |
ROLLER
|
ZED
|
| 31. |
130007
|
[3] |
COTTER PIN,M4 x 25
|
NH
Superseded by part number: 83903970
|
