| . . | NSS | [1] | NOT SOLD SEPARAT | CONHYD LINES, UPP |
| . . | YY03H00050F1 | [1] | HYD LINES, UPP | |
| A1. | YY03H01107D1 | [1] | HOSE | KOB, Serial Range: YL04-00501-YL04-00551 Superseded by part number: YY03H01146D1 |
| . . | YY03H01146D1 | [1] | HOSE | KOB, Start Serial: YL04-00552 |
| A2. | YY03H01110D1 | [1] | HOSE | KOB, Serial Range: YL04-00501-YL04-00551 Superseded by part number: YY03H01149D1 |
| . . | YY03H01149D1 | [1] | HOSE | KOB, Start Serial: YL04-00552 |
| A3. | YY03H01109D1 | [1] | HOSE | KOB, Serial Range: YL04-00501-YL04-00551 Superseded by part number: YY03H01148D1 |
| . . | YY03H01148D1 | [1] | HOSE | KOB, Start Serial: YL04-00552 |
| A4. | YY03H01110D2 | [1] | HOSE | KOB, Serial Range: YL04-00501-YL04-00551 Superseded by part number: YY03H01149D2 |
| . . | YY03H01149D2 | [1] | HOSE | KOB, Start Serial: YL04-00552 |
| A5. | YY03H01110D3 | [1] | HOSE | KOB, Serial Range: YL04-00501-YL04-00551 Superseded by part number: YY03H01149D3 |
| . . | YY03H01149D3 | [1] | HOSE | KOB, Start Serial: YL04-0552 |
| A6. | YY03H01108D1 | [1] | HOSE | KOB, Serial Range: YL04-00501-YL04-00551 Superseded by part number: YY03H01147D1 |
| . . | YY03H01147D1 | [1] | HOSE | KOB, Start Serial: YL04-00552 |
| A7. | YY03H01108D2 | [1] | HOSE | KOB, Serial Range: YL04-00501-YL04-00551 Superseded by part number: YY03H01147D2 |
| . . | YY03H01147D2 | [1] | HOSE | KOB, Start Serial: YL04-00552 |
| A8. | ZD12P01800 | [8] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A9. | YM30H01008P1 | [1] | FLANGE | KOB |
| A10. | YR03H01125P1 | [3] | HYD CONNECTOR | KOB |
| A11. | HH25R08004G1 | [1] | HYD CONNECTOR | KOB1/4"PFx1/2"PFx36mm Long (Incls. O-Ring ZD12P01800) |
| A12. | PH32H01006P1 | [1] | HYD CONNECTOR | KOB |
| A13. | 2444Z3715 | [4] | 90 ELBOW | KOB90° -- 1/2" PF x 56mm Long (Incls. O-Ring ZD12P01800) |
| A14. | ZH42X08000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 45° -- (Incls. O-Ring ZD12P01800) |
| A15. | ZA33F15008 | [4] | ELBOW | KOB, Serial Range: YLO4-00501-YL04-00551 |
| . . | LC03H01233P1 | [4] | ELBOW | KOB, Start Serial: YL04-00552 Superseded by part number: ZA38F15008 |
| A16. | ZA33F18008 | [3] | ELBOW | KOB, Serial Range: YL04-00501-YL04-00551 |
| . . | YT19H01015P1 | [3] | ELBOW | KOB, Start Serial: YL04-00552 Superseded by part number: ZA38F18008 |
| A17. | HH55Q08008G3 | [1] | TEE,PF 1/2" x PF 1/2", O-Ring | KOB(PF 1/2) (Incls. O-Ring ZD12P01800) |
| A18. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| A19. | YN03H01169P1 | [1] | GROMMET | KOB |
| A20. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| A21. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| A22. | ZS28C10045 | [4] | SCREW,Hex Socket Head, M10 x 45mm | KOBM10x1.50x45mm |
| A23. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| A24. | ZA23F18008 | [1] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied), Serial Range: YL04-00501-YL04-00551 |
| . . | YT19H01016P1 | [1] | CONNECTION | KOB, Start Serial: YL04-00552 Superseded by part number: ZA28F18008 |
| . . | YY19H00012F1 | [1] | HYD LINES, SWIVEL | |
| B1. | HG33F10016G1 | [2] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long |
| B2. | HG34F10016G1 | [2] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 100mm Long |
| B3. | YX19H01001P1 | [1] | ELEC CONNECTOR | KOB |
| B4. | ZD12A01800 | [4] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| B5. | ZD12P01400 | [4] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B6. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B7. | YY03H01111P1 | [2] | HYD CONNECTOR | KOB |
| B8. | 2444Z3713 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| B9. | ZA23F15006 | [3] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied), Serial Range: YL04-00501-YL04-00551 |
| . . | YY19H01003P1 | [3] | HYD CONNECTOR | KOB, Start Serial: YL04-00552 Superseded by part number: ZA28F15006 |
| B10. | ZA23F18008 | [1] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied), Serial Range: YL04-00501-YL04-00551 |
| B11. | 2444Z3155 | [4] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| B12. | ZA33F15006 | [1] | ELBOW | KOB, Serial Range: YL04-00501-YL04-00551 |
| . . | YY19H01004P1 | [1] | ELBOW | KOB, Start Serial: YL04-00552 Superseded by part number: ZA38F15006 |
| B13. | ZA33F18008 | [1] | ELBOW | KOB, Serial Range: YL04-00501-YL04-00551 |
