| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| . . | YY32H00006F1 | [1] | HYD LINES, RETURN | |
| 1. | ZX23M08185 | [1] | HOSE | KOB |
| 2. | YN20M01046D9 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1700.00mm | KOBProtective Plastic |
| 3. | ZH32X08012 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 3/4", O-Ring | KOB90° -- 1/2"PFx3/4"PFx66mm Long (Incls. O-Ring ZD12P02400) |
