纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-069-00[01]) - HYDRAULIC CIRCUIT - OPTIONAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
139 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUB0157 | [1] | ARM | SUM |
| 46. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 47. | 154475A1 | [1] | O-RING | SUM |
| 48. | KUJ0291 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1500.00 mm | SUM |
| 49. | HEJ0119 | [1] | COLLAR | SUM |
| 50. | HEJ0121 | [1] | COLLAR | SUM |
| 51. | 166351A1 | [1] | BOLT,Sems, M10 x 20mm | SUM |
| 52. | KUJ0292 | [1] | BRACKET | SUM |
| 53. | 166347A1 | [2] | BOLT,Sems, M10 x 30mm | SUM |
| 56. | KHJ1810 | [1] | VALVE | SUM Superseded by part number: KHJ17390 |
| 57. | 102R005Y045R | [2] | BOLT | SUMM5 x 45; 10.9 |
| 58. | 892-11005 | [2] | LOCK WASHER,M5 | CAS Superseded by part number: 10569179 |
| 59. | 182-005SR | [2] | WASHER | SUM |
| 60. | KUJ0300 | [1] | BRACKET | SUM |
| 61. | 167182A1 | [2] | BOLT,Sems, M8 x 25mm | SUM |
| 62. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 64. | KHJ2284 | [1] | HYDRAULIC HOSE,9.50 mm ID x 500.00 mm | SUM |
| 65. | KUJ0298 | [1] | MANIFOLD VALVE | SUM |
| 66. | 166052A1 | [4] | BOLT | SUM Superseded by part number: 11106231 |
| 67. | KUJ0288 | [1] | SOLENOID VALVE | SUM |
| 68. | 153105A1 | [1] | PLUG | SUM |
| 72. | 164107A1 | [1] | TEE,3/8" ORB x 3/8" - 19 NPT x 3/8" - 19 NPT | SUM |
| 74. | 159226A1 | [1] | ADAPTER | SUM |
| 78. | KUB0181 | [1] | BRACKET | SUM |
| 79. | 627-12035 | [2] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 80. | 150811A1 | [2] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 82. | KHJ1539 | [1] | HYDRAULIC HOSE,9.52 mm ID x 500.00 mm | SUM |
| 115. | KHJ2286 | [1] | HYDRAULIC HOSE,9.50 mm ID x 3500.00 mm | SUM |
| 123. | KHJ1819 | [1] | HYDRAULIC HOSE | SUM |
| 127. | KUB0182 | [1] | BRACKET | SUM |
| 128. | 166352A1 | [2] | BOLT | SUM |
| 129. | HEJ0122 | [4] | HOSE CLAMP | SUM |
| 130. | KUJ0293 | [2] | CLAMP | SUM |
| 131. | 166346A1 | [2] | BOLT,Sems, M10 | SUM |
| 135. | 150409A1 | [1] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 136. | 162R010VR | [1] | NUT | SUM Superseded by part number: 86500689 |
| 155. | KHJ2395 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1550.00 mm | SUM |
| 164. | 159497A1 | [1] | TEE | SUM |
| 165. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 166. | 160439A1 | [1] | HOSE ASSY. | SUM2400 mm (94-7/16 in) |
| 169. | KHJ1608 | [1] | HOSE | SUM |
| 170. | 162554A1 | [1] | FITTING | SUM |
| 172. | 158186A1 | [1] | PRESSURE RELIEF VALVE | SUM Superseded by part number: KHJ26180 |
| 173. | 158183A1 | [1] | ELEC CONNECTOR,Male | SUM |
| 175. | 167321A1 | [1] | TEE | SUM |
| 176. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 178. | 157851A1 | [1] | HOSE | SUM2850 mm (112-1/4 in) |
| 195. | 150860A1 | [1] | COLLAR | SUM |
| 196. | 145N006S008R | [1] | SCREW,Pan Hd, M6 x 8mm, Cl 10.9 | SUM |
| 197. | 150496A1 | [1] | MOUNTING CLIP | SUM |
| 198. | 158962A1 | [1] | CLIP | SUM |
| 199. | 167518A1 | [1] | BOLT | SUM |
