纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-077-00[01]) - HYDRAULIC CIRCUIT - OPTIONAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
512 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 34. | KUB0156 | [1] | HYDRAULIC CYLINDER | SUM |
| 99. | KHJ2284 | [1] | HYDRAULIC HOSE,9.50 mm ID x 500.00 mm | SUM |
| 100. | KUJ0289 | [1] | PRESSURE RELIEF VALVE | SUM |
| 101. | 827-8060 | [2] | BOLT,Hex, M8 x 1.25 x 60mm, Cl 10.9 | CAS Superseded by part number: 86625005 |
| 102. | 895-10008 | [2] | WASHER,M8 x 16 x 1.6 | CAS9 x 16 x 1,6 mm Superseded by part number: 86624185 |
| 103. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 104. | 154475A1 | [1] | O-RING | SUM |
| 105. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 109. | KHJ1539 | [1] | HYDRAULIC HOSE,9.52 mm ID x 500.00 mm | SUM |
| 110. | KRJ5868 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1750.00 mm | SUM |
| 115. | KHJ2286 | [1] | HYDRAULIC HOSE,9.50 mm ID x 3500.00 mm | SUM |
| 117. | 158065A1 | [2] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHR21050 |
| 123. | KHJ1819 | [1] | HYDRAULIC HOSE | SUM |
| 137. | KUJ0302 | [1] | BRACKET | SUM |
| 138. | 166052A1 | [2] | BOLT | SUM Superseded by part number: 11106231 |
| 139. | KUJ0293 | [1] | CLAMP | SUM |
| 140. | HEJ0122 | [2] | HOSE CLAMP | SUM |
| 141. | 166346A1 | [1] | BOLT,Sems, M10 | SUM |
| 145. | KUJ0305 | [1] | BRACKET | SUM |
| 146. | 166347A1 | [2] | BOLT,Sems, M10 x 30mm | SUM |
| 147. | KUJ0304 | [1] | MANIFOLD | SUM |
| 148. | 814-10100 | [2] | BOLT,Hex, M10 x 1.5 x 100mm, Cl 8.8 | CASM10 x 100; 10.9 Superseded by part number: 120075 |
| 154. | KHJ2395 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1550.00 mm | SUM |
