纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-077-11[01]) - COUNTERWEIGHT REMOVAL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
844 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 137. | KUJ0302 | [1] | BRACKET | SUM |
| 138. | 166052A1 | [2] | BOLT | SUM Superseded by part number: 11106231 |
| 139. | KUJ0293 | [1] | CLAMP | SUM |
| 140. | HEJ0122 | [2] | HOSE CLAMP | SUM |
| 141. | 166346A1 | [1] | BOLT,Sems, M10 | SUM |
| 145. | KUJ0305 | [1] | BRACKET | SUM |
| 146. | 166347A1 | [2] | BOLT,Sems, M10 x 30mm | SUM |
| 147. | KUJ0304 | [1] | MANIFOLD | SUM |
| 148. | 814-10100 | [2] | BOLT,Hex, M10 x 1.5 x 100mm, Cl 8.8 | CAS Superseded by part number: 120075 |
| 149. | 150916A1 | [2] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 150. | 154475A1 | [1] | O-RING | SUM |
| 151. | 152128A1 | [4] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 154. | KHJ2395 | [4] | HYDRAULIC HOSE,9.50 mm ID x 1550.00 mm | SUM |
