纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-079-01[01]) - HIGH PRESSURE HYDRAULIC PUMP - HYDRAULIC PUMP, PILOT CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1007 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LJ00575 | [1] | PUMP, HYDRAULIC | SUM Superseded by part number: LJ01287 |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 5. | 160593A1 | [1] | SPRING | SUM |
| 6. | LV00027 | [1] | SCREW,Spcl | SUM |
| 7. | 163662A1 | [1] | LOCK NUT | SUM |
| 11. | 163663A1 | [1] | FILTER | SUM |
| 13. | LA00593 | [2] | BOLT,Hex Skt, M8 x 50mm, Cl 12.9 | SUM |
| 14. | LA00594 | [2] | BOLT,Hex Skt, M8 x 65mm, Cl 12.9 | SUM |
| 15. | LA00592 | [4] | BOLT,Hex Skt, M10 x 30mm, Cl 12.9 | SUM |
| 16. | LLM0111 | [1] | PLUG | SUM |
| 17. | 163667A1 | [1] | SEALING RING | SUM |
| 18. | 154733A1 | [1] | O-RING | SUM |
| 19. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 20. | 154483A1 | [1] | O-RING | SUM |
| 21. | 163668A1 | [1] | RING, LOCKING | SUM |
