纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-079-01[02]) - HIGH PRESSURE HYDRAULIC PUMP - HYDRAULIC PUMP, PILOT CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
624 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 240. | LJ01287 | [1] | HYDRAULIC PUMP | SUM |
| 241. | LC00260 | [1] | GEAR | SUM |
| 242. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 248. | LE01175 | [1] | RING | SUM |
| 249. | LG00536 | [1] | SPRING | SUM |
| 250. | LF00043 | [1] | ADJUSTER | SUM |
| 251. | 163662A1 | [1] | LOCK NUT | SUM |
| 252. | 163663A1 | [1] | FILTER | SUM |
| 253. | LA00593 | [2] | BOLT,Hex Skt, M8 x 50mm, Cl 12.9 | SUM |
| 254. | LA00594 | [2] | BOLT,Hex Skt, M8 x 65mm, Cl 12.9 | SUM |
| 255. | LA00592 | [4] | BOLT,Hex Skt, M10 x 30mm, Cl 12.9 | SUM |
| 256. | LLM0111 | [1] | PLUG | SUM |
| 257. | 163667A1 | [1] | SEALING RING | SUM |
| 258. | 154733A1 | [1] | O-RING | SUM |
| 259. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 260. | 154483A1 | [1] | O-RING | SUM |
| 261. | 163668A1 | [1] | RING, LOCKING | SUM |
