纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-079-04[01]) - HIGH PRESSURE HYDRAULIC PUMP - REGULATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
274 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 153. | 108R006Z070N | [4] | BOLT | SUM |
| 155. | 861-8070 | [2] | HEX SOC SCREW,M8 x 70mm, Cl 12.9 | CASM8 x 70; 12.9 |
| 156. | 861-6030 | [2] | HEX SOC SCREW,M6 x 30mm, Cl 12.9 | SUMM6 x 30; 12.9 Superseded by part number: 108R006Z030N |
| 157. | 862-6020 | [6] | HEX SOC SCREW,M6 x 20mm, Cl 12.9 | CASM6 x 20; 12.9 |
| 158. | 155496A1 | [1] | PLUG | SUM |
| 159. | LK00003 | [7] | PLUG | SUM |
| 160. | TPP0095 | [2] | VALVE SEAT | SUM |
| 161. | TPP0094 | [2] | STOP | SUM |
| 162. | 156966A1 | [2] | BALL | SUM |
| 163. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 193. | 154447A1 | [3] | O-RING | SUM |
| 194. | 154455A1 | [8] | O-RING | SUM |
| 195. | 154463A1 | [1] | O-RING | SUM |
| 201. | 154471A1 | [1] | O-RING | SUM |
| 202. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 216. | LJ00684 | [1] | SOLENOID VALVE | SUM |
| 223. | 155203A1 | [1] | O-RING | SUM |
| 224. | 155204A1 | [1] | O-RING | SUM |
| 225. | 160652A1 | [1] | O-RING | SUM |
| 226. | LL00055 | [1] | SOLENOID | SUM |
