纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-097-00[01]) - CONTROL PEDAL TRAVEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
894 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | KTJ2034 | [1] | CONTROL BLOCK | SUM Superseded by part number: KHJ19280 |
| 1. | 165203A1 | [1] | SET OF PARTS | SUM |
| 2. | 165209A1 | [1] | HOUSING | SUM |
| 3. | LSC0235 | [4] | SPOOL | SUM |
| 4. | LK00003 | [2] | PLUG | SUM |
| 5. | 165211A1 | [2] | COVER | SUM |
| 6. | 165197A1 | [4] | PLUG | SUM |
| 7. | 165210A1 | [4] | CAP | SUM |
| 8. | LE00768 | [1] | OIL SEAL | SUM |
| 9. | 165195A1 | [4] | SCRAPER RING | SUM |
| 10. | 166804A1 | [4] | O-RING | SUM |
| 11. | 165229A1 | [4] | PUSH ROD | SUM |
| 12. | LA00056 | [8] | WASHER | SUM |
| 13. | LA00057 | [4] | SET OF WASHERS | SUM |
| 14. | 165205A1 | [4] | SPRING SEAT | SUM |
| 15. | 165198A1 | [4] | RING, SNAP | SUMSNAP RING |
| 16. | 165196A1 | [4] | BUSHING | SUM |
| 17. | 165199A1 | [4] | PISTON | SUM |
| 18. | 165200A1 | [12] | BALL | SUM |
| 19. | 862-12055 | [2] | HEX SOC SCREW,M12 x 55mm, Cl 12.9 | CASM12 x 55; 12,9 |
| 20. | 165206A1 | [4] | SPRING SEAT | SUM |
| 21. | 160283A1 | [4] | WASHER | SUM |
| 22. | LG00389 | [4] | COMPRESSION SPRING | SUM |
| 23. | 160250A1 | [4] | SPRING | SUM |
| 24. | 165277A1 | [4] | SPRING | SUM |
| 25. | 165208A1 | [4] | SPRING | SUM |
| 26. | 160035A1 | [4] | BUSHING | SUM |
| 27. | 160022A1 | [2] | SHAFT | SUM |
| 28. | 160090A1 | [2] | CAM | SUM |
| 29. | LUC0103 | [2] | SCREW | SUM |
| 30. | 160282A1 | [4] | SCREW | SUM |
| 31. | 160281A1 | [4] | LOCK NUT | SUM |
| 32. | 160001A1 | [2] | BELLOWS | SUM |
