纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-127-00[01]) - CYLINDER ASSY BOOM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
586 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | KUV0186 | [2] | HYDRAULIC CYLINDER | SUM |
| . . | LR00455 | [1] | HYD CYL SLEEVE | SUM |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | KUV0037 | [1] | BUSHING | SUM |
| . . | LB00451 | [1] | PISTON ROD | SUM |
| 6. | KUV0036 | [1] | BUSHING | SUM |
| . . | LU00058 | [1] | CYLINDER END CAP | SUM |
| 8. | LU00059 | [1] | CYLINDER END CAP | SUM Superseded by part number: LU00165 |
| 9. | LB00460 | [1] | BUSHING | SUM |
| 10. | LA00622 | [1] | RING | SUM |
| 11. | LE00615 | [1] | RING | SUM |
| 12. | LAU0070 | [1] | RING | SUM |
| 13. | LE00616 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 14. | LE00617 | [1] | SEALING STRIP | SUM |
| 15. | LE00980 | [1] | RING | SUM Superseded by part number: LE015230 |
| 16. | 154877A1 | [1] | O-RING | SUM |
| 17. | LE00619 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 18. | 108R030W100N | [8] | BOLT | SUM |
| 19. | LG00281 | [1] | RING | SUM |
| 20. | LE00620 | [1] | SEAL | SUM |
| 21. | LJ00625 | [1] | JACK PISTON | SUM |
| 22. | LE00621 | [1] | RING | SUM |
| 23. | LE00622 | [2] | SEALING STRIP | SUM |
| 24. | LE00623 | [2] | SEALING STRIP | SUM |
| 25. | LH00212 | [1] | SHIM | SUM |
| 26. | LA00618 | [1] | SPECIAL NUT | SUM |
| 27. | LA00617 | [1] | SCREW,Hex Skt | SUM |
| 28. | LB00459 | [1] | BALL | SUM |
| 29. | LE00653 | [4] | WIPER SEAL | SUM |
| 30. | LJ00624 | [1] | BLEEDER | SUM |
| 31. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 32. | M01X0813 | [1] | NIPPLE, LUBE | SUM |
| . . | LZ00312 | [1] | SEAL KIT | SUM |
