纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-129-00[01]) - CUSHION VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
537 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | KUJ0101 | [1] | VALVE, CUSHION | SUM |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 4. | LBQ0060 | [2] | O-RING | SUM Superseded by part number: 154446A1 |
| 5. | LSJ0001 | [4] | SPRING | SUM Superseded by part number: 160256A1 |
| 6. | LLJ0004 | [4] | PLUG | SUM Superseded by part number: 160073A1 |
| 7. | LBQ0140 | [4] | O-RING | SUM Superseded by part number: 154474A1 |
| 8. | LSJ0002 | [4] | SPRING | SUM Superseded by part number: 160257A1 |
| 12. | LSJ0003 | [4] | SPRING | SUM Superseded by part number: 160258A1 |
| 14. | LLJ0005 | [4] | PLUG | SUM Superseded by part number: 160074A1 |
| 15. | LBQ0180 | [4] | O-RING | SUM Superseded by part number: 154486A1 |
| 16. | LLC0156 | [11] | PLUG | SUM |
| 18. | LLS0053 | [8] | PLUG | SUM Superseded by part number: 165002A1 |
