凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (18.87732915[01]) - DIA : KNOTTER & NEEDLE INSPECTION LIGHT KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
426 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
87732915
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
86643190
|
[3] |
LAMP,Halogen, 12V, 36W, Clear
|
ZED
|
| 2. |
84320248
|
[1] |
LIGHT SWITCH
|
ZED
|
| 3. |
87383653
|
[1] |
WIRE HARNESS
|
ZED
|
| 4. |
86566990
|
[30] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP
|
| 5. |
9839372
|
[1] |
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
|
| 6. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 7. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
84124096
|
[3] |
SUPPORT
|
ZED
|
