纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-139-01[01]) - HYDRAULICS BOOM - WITH LOAD HOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
419 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 6. | 157580A1 | [2] | ELBOW,90º, 3/4" O-Ring x 3/4" | SUM |
| 7. | 154503A1 | [1] | O-RING | SUM |
| 8. | KUV0330 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1400.00 mm | SUM |
| 9. | KUV0269 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1200.00 mm | SUM |
| 10. | KHV0462 | [2] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHV11610 |
| 11. | 150067A1 | [4] | MOUNTING CLIP | SUM150 mm (6 in) |
| 12. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 13. | 154475A1 | [1] | O-RING | SUM |
| 14. | 152760A1 | [1] | HOSE | SUM Superseded by part number: 152758A1 |
| 15. | 150774A1 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHH12760 |
| 19. | 152757A1 | [1] | HOSE ASSY. | SUM |
| 22. | 157584A1 | [1] | ELBOW | SUM |
| 24. | 152753A1 | [1] | HOSE,95.00 mm ID x 1100.00 mm | SUM |
| 29. | KHJ1607 | [1] | HYDRAULIC HOSE | SUM |
| 32. | 152127A1 | [2] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 33. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 34. | 157846A1 | [1] | HOSE ASSY.,6.30 mm ID x 650.00 mm | SUM |
| 35. | 157767A1 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHH12760 |
| 37. | KUV0186 | [2] | HYDRAULIC CYLINDER | SUM |
