神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-012) - FUEL LINES Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
777 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21P00002F1 | [1] | LINE | KOBFUEL |
| 6. | 2444R2492D085 | [1] | HOSE | KOB850mm Long (33-15/32 in) |
| 7. | 2444R2492D150 | [1] | HOSE | KOB1500mm Long (59-3/64 in) |
| 8. | 2444R2492D250 | [1] | HOSE,9.5mm ID x 900mm L | KOB |
| 9. | 2418Z1333D20 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 800mm Length | KOBProtective Plastic |
| 10. | 2418Z1333D6 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1400mm Length | KOB |
| 11. | 2418Z1333D33 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 2400mm Length | KOBProtective Plastic |
| 12. | ZC16X01800 | [6] | CLIP | KOBClamp, Hose -- Min 12 x Max 22mm |
| 13. | PY01P01043D3 | [6] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 14. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOBWire Ties -- 292mm Long |
| 15. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 16. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 17. | HX11Y04030DX | [1] | HOSE,6mm ID x 300mm L | KOB |
| 18. | YX21P01004P1 | [1] | GROMMET | KOB |
| 1. | VI8972186470 | [1] | OIL SEPARATOR | KOBWATER |
| 2. | VI5154112231 | [2] | PIPE | KOBCONNECTOR |
| 3. | VI9095720140 | [4] | PACKING | KOB |
| 4. | VI9099063251 | [1] | BOLT | KOB Superseded by part number: 87596570 |
| 5. | VI5157590270 | [1] | BOLT | KOB(WITH GAUZE FILTER) |
