神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-013) - TANK ASSY, FUEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
233 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY20P00006F1 | [1] | TANK | KOBASSY, FUEL |
| A1. | YY20P00008P1 | [1] | TANK | KOBFUEL |
| A2. | YY50V00001P1 | [1] | STRAINER ASSY. | KOB |
| A3. | YN20P01034P1 | [1] | CAP | KOB, Serial Range: YH02-01301-YH02-02096 Superseded by part number: YN20P01034P2 |
| A3. | YN20P01034P2 | [1] | CAP | KOBFuel Tank Filler, Start Serial: YH03-02097- |
| A4. | YX20P01020P1 | [1] | FLANGE | KOB |
| A5. | ZD11P13000 | [1] | O-RING | KOBID 129.6 ± 1.05 x OD 140mm |
| A6. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| A7. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| . . | YY20P00007F1 | [1] | TANK | KOBINSTAL, FUEL |
| B1. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| B2. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| B3. | YN52S00034F1 | [1] | SENSOR | KOBASSY, LEVEL |
| B4. | 2418T9962 | [1] | PACKING | KOBID 41 x OD 68 x Th 2.0mm |
| B5. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBM05x0.8x12mm |
| B6. | ZW26X05000 | [5] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| B8. | 2436R339 | [1] | COCK, DRAIN | KOB |
| B9. | YN22C01099D9 | [2] | WEATHERSTRIP | KOB |
| B10. | YX20P01005P1 | [1] | PLATE | KOB |
| B11. | ZM32C12030 | [1] | BOLT | KOBM12x1.75x30mm (Incls. Washer & Lockwasher) |
| B13. | YY20P01028P1 | [1] | INDICATOR | KOB |
| B14. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| B15. | ZW26X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| B16. | 2418T10357 | [1] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| B17. | LE33H01017D1 | [1] | SHIM,1.0mm Thk | KOB(1.0) |
| B18. | LE33H01017D2 | [1] | SHIM | KOB(0.5) |
| B19. | YY20P01026D1 | [1] | INDICATOR | KOB |
| B20. | YY20P01027D1 | [1] | INDICATOR | KOB |
| B21. | YN21C01528D8 | [1] | WEATHERSEAL STRIP | KOB510mm Long (20-5/64 in) |
| B22. | YJ21C01154D4 | [1] | RUBBER | KOB |
