纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-143-00[01]) - SECOND OPTION - LINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
911 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUV0339 | [2] | HYD. TUBE,20.8 mm ID x 27.2 mm OD | SUM |
| 2. | KHJ1284 | [2] | ADAPTER | SUM |
| 3. | 154503A1 | [1] | O-RING | SUM |
| 4. | 168970A1 | [2] | VALVE | SUM |
| 7. | KUV0340 | [1] | HYD. TUBE,20.8 mm ID x 27.2 mm OD | SUM |
| 8. | KUV0341 | [1] | HYD. TUBE,20.8 mm ID x 27.2 mm OD | SUM |
| 9. | KUV0342 | [1] | HYD. TUBE,21.6 mm ID x 27.2 mm OD | SUM |
| 12. | KUV0343 | [2] | HYD. TUBE,20.8 mm ID x 27.2 mm OD | SUM |
| 14. | KSV1632 | [2] | HYDRAULIC HOSE,19.05 mm ID x 2050.00 mm | SUM |
| 24. | 151486A1 | [9] | CLAMP BRACKET | SUM |
| 25. | 152085A1 | [9] | COLLAR | SUM |
| 26. | 167183A1 | [18] | BOLT,Sems, M12 x 60mm, Cl 10.9 | SUM |
