| 13. | 150496A1 | [1] | MOUNTING CLIP | SUM |
| 17. | KHJ1248 | [1] | HYDRAULIC HOSE | SUM |
| 18. | 158186A1 | [1] | PRESSURE RELIEF VALVE | SUM Superseded by part number: KHJ26180 |
| 19. | KHJ1178 | [1] | ELBOW | SUM |
| 20. | 162654A1 | [1] | HYD CONNECTOR | SUM |
| 21. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 22. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 40. | 161293A1 | [1] | HOSE | SUM |
| 45. | KSV1633 | [1] | HYDRAULIC HOSE,19.05 mm ID x 2050.00 mm | SUM |
| 46. | KUJ0445 | [2] | HYDRAULIC HOSE,19.00 mm ID x 2050.00 mm | SUM |
| 48. | KUJ0423 | [1] | TUBE ASSY.,21.6 mm ID x 27.2 mm OD | SUM |
| 49. | KUJ0424 | [1] | TUBE ASSY.,20.8 mm ID x 27.2 mm OD | SUM |
| 50. | KUJ0425 | [1] | TUBE ASSY.,20.8 mm ID x 27.2 mm OD | SUM |
| 51. | KUJ0430 | [1] | SUPPORT | SUM |
| 52. | KUJ0431 | [1] | SUPPORT | SUM |
| 53. | 627-12035 | [4] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 54. | 150811A1 | [4] | WASHER | SUM Superseded by part number: 86625255 |
| 55. | 152742A1 | [2] | COLLAR | SUM |
| 56. | 151486A1 | [2] | CLAMP BRACKET | SUM |
| 57. | 827-12065 | [4] | BOLT,Hex, M12 x 1.75 x 65mm, Cl 10.9 | CAS Superseded by part number: 86624980 |
| 58. | 829-1412 | [4] | NUT,M12, Cl 10 | CAS Superseded by part number: 337475 |
| 60. | KUJ0437 | [1] | HYDRAULIC HOSE,19.00 mm ID x 650.00 mm | SUM |
| 61. | 157580A1 | [1] | ELBOW,90º, 3/4" O-Ring x 3/4" | SUM |
| 62. | 154503A1 | [1] | O-RING | SUM |
| 63. | KUV0330 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1400.00 mm | SUM |
| 64. | KNJ2036 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1350.00 mm | SUM |
| 67. | KHJ2451 | [2] | FIXING BRACKET | SUM |
| 68. | 159602A1 | [1] | BOLT,Sems, Hex, M6 x 16mm | SUM |
| 69. | KUJ0429 | [1] | SUPPORT | SUM |
| 70. | 152718A1 | [1] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 91. | KUJ0436 | [1] | HYDRAULIC HOSE,31.80 mm ID x 940.00 mm | SUM |
