纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-148-00[01]) - LOW FLOW CIRCUIT - DIPPER 5M61 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
139 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87416721 | [3] | VANEUM GAUGE | CAS |
| 2. | 87416722 | [3] | PLUG | CAS |
| 3. | 428733A1 | [6] | SEAL | CAS |
| 4. | 428958A1 | [3] | ADAPTER | CAS |
| 5. | 827-6060 | [6] | BOLT,Hex, M6 x 60mm, Cl 10.9 | CAS Superseded by part number: 86639189 |
| 6. | 829-1406 | [6] | NUT,Hex, M6 x 1, Cl 10.9 | CAS Superseded by part number: 86500688, 87778396 |
| 7. | 87416723 | [3] | HOLDER | CAS |
| 8. | 87416730 | [2] | PIPE ASSY. | CAS |
| 9. | 87416731 | [1] | PIPE ASSY. | CAS |
| 10. | 86987663 | [4] | HOLDER | CAS |
| 11. | 86987664 | [8] | HALF-FLANGE | CAS |
| 12. | 827-16070 | [4] | BOLT,Hex, M16 x 2 x 70mm, Cl 10.9 | CAS Superseded by part number: 87015545 |
| 13. | 829-1416 | [4] | NUT,M16, Cl 10 | CAS Superseded by part number: 392530 |
| 14. | 87416726 | [2] | HOSE | CAS |
| 15. | 87416727 | [1] | HOSE | CAS |
