神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-034) - CAB INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
482 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV02C00001F2 | [1] | CAB | KOBINSTAL Superseded by part number: ZW26X10000, ZS18C10025, ZW16H10000, YT02C01282P1, YY02C01012P1, ZM61C06016, YT02C01126D7, YT54C00003F1, ZM22C08020, YN03M01159P1 |
| A1. | ZS18C10025 | [5] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| A2. | ZW26X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A3. | ZW16H10000 | [5] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| A4. | YT54C00003F1 | [1] | TANK | KOBASSY |
| A4-1. | YT54C00003S001 | [1] | ELECTRIC MOTOR | KOB |
| A4-2. | YT54C00003S002 | [1] | TANK | KOBASSY, WATER |
| A4-3. | YT54C00003S003 | [1] | BRACKET | KOB Superseded by part number: 2416P7292 |
| A5. | ZM61C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| A6. | YT02C01126D7 | [1] | TUBE | KOB900mm Long (35-7/16 in) |
| A7. | YT02C01282P1 | [1] | ELEC CONNECTOR | KOB30mm Long (1-13/16 in) |
| A8. | YN03M01159P1 | [1] | GROMMET | KOB |
| A10. | ZM22C08020 | [2] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| A11. | YV02C01003P1 | [1] | BRACKET | KOB Superseded by part number: YY02C01012P1 |
| B1. | YT02C00030F9 | [1] | CAB | KOBASSY,SEE FIG 01-035 |
