神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-033) - MIRROR INSTAL GROUP, P/N YY52C00003F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
606 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY52C00003F1 | [1] | MIRROR | KOBMIRROR INSTAL |
| 1. | YY52C01007P1 | [1] | STAY | KOBSTAY |
| 2. | YY52C01003P1 | [1] | CLAMP | KOB |
| 3. | 2456Z253 | [1] | MIRROR | KOBBACK |
| 4. | YY52C01006P1 | [1] | SUPPORT | KOB |
| 5. | ZS18C08045 | [2] | SCREW,Hex, M8 x 45mm | KOBM08x1.25x45mm |
| 6. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 7. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 8. | ZW16X12000 | [2] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 9. | R16T0137D1 | [4] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 0.9mm |
| 10. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
