神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-038) - CAB & GUARD ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
426 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT01C00003F2 | [1] | KIT | KOBCAB & GUARD ASSY Superseded by part number: YT01C01012P1, YT02C01410P1, YT01C01022P1, YT02C01475P1, YT01C01024P1, YT01C01023P1, YT01C01020P1, YT01C01017P1, YR21C01161P1, YT01C01018P1, YT01C01016P1, YT01C01009P1, YT01C01008P1, YT01C01021P1, YT01C01007P1, YT01C01004P1, YT01C01013P1, YT01C01005P1, ZM11C08016, YT01C01010P1, YT01C01019P1 |
| . . | YT01C00003F3 | [1] | CAB & GUARD ASSY | |
| 1. | YT01C01018P1 | [1] | GUARD | KOB |
| 2. | YT01C01019P1 | [1] | GUARD | KOB |
| 3. | YT01C01020P1 | [1] | GUARD | KOB |
| 4. | YT01C01004P1 | [1] | GUARD | KOB |
| 5. | YT01C01005P1 | [1] | GUARD | KOB |
| 6. | YT01C01023P1 | [1] | GUARD | KOB |
| 7. | YT01C01007P1 | [1] | GUARD | KOB |
| 8. | YT01C01008P1 | [1] | GUARD | KOB |
| 9. | YT01C01009P1 | [1] | GUARD | KOB |
| 10. | YT01C01010P1 | [1] | GUARD | KOB |
| 11. | YT01C01022P1 | [1] | GUARD | KOB |
| 12. | YT01C01012P1 | [1] | GUARD | KOB |
| 13. | YT01C01013P1 | [1] | GUARD | KOB |
| 16. | YT01C01016P1 | [1] | PLATE | KOB |
| 17. | YT01C01017P1 | [1] | PLATE | KOB |
| 18. | YT02C01475P1 | [1] | BOX | KOB |
| 19. | ZM11C08016 | [14] | BOLT | KOBM08x1.25x16mm (Incls. Lockwasher) |
| 20. | YR21C01161P1 | [14] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOBID 09 x OD 22 x Th 2.3mm |
| 21. | YT01C01021P1 | [3] | RUBBER | KOB |
| 22. | YT02C01410P1 | [1] | COVER | KOB |
| 23. | YT01C01024P1 | [1] | GUARD | KOB(F2 ONLY) |
| 24. | YT01C01025P1 | [1] | GUARD | KOB(F3 ONLY) |
