凯斯零件查询(LB333R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (01.06[01]) - FLYWHEEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
586 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87721200
|
[1] |
BALER FLYWHEEL
|
ZED
(2)
|
| 1. |
87720102
|
[1] |
BALER FLYWHEEL
|
ZED
(2)
|
| 2. |
87695682
|
[1] |
SHEAR BOLT BUSHING,10.2mm ID x 31.7mm OD x 38mm L
|
ZED
|
| 3. |
87660055
|
[1] |
INSERT
|
ZED
|
| 4. |
84800487
|
[1] |
HUB
|
ZED
|
| 5. |
84062069
|
[1] |
DISC
|
ZED
|
| 6. |
412677
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 12.9, Full Thd
|
ZED
|
| 7. |
84062386
|
[1] |
RING,55mm ID x 88.4mm OD
|
ZED
|
| 8. |
853116
|
[2] |
TAPERED BEARING
|
ZED
Superseded by part number: 87555831
|
| 9. |
62161
|
[1] |
LUBE NIPPLE,M8 x 1.25, Str
|
NH
|
| 10. |
83931335
|
[6] |
BOLT,Hex, M10 x 1.5 x 75mm, Cl 8.8
|
ZED
|
| 10. |
86624979
|
[6] |
BOLT,Hex, M10 x 75mm, Cl 10.9
|
FAR
|
| 11. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
84062070
|
[1] |
LOCKING PLATE
|
ZED
|
| 13. |
84062423
|
[1] |
SHIM
|
ZED
1 mm Thk, Serial Range: -C867
|
| 13. |
84293744
|
[1] |
ADJUSTING PLATE
|
ZED
1 mm Thk, Start Serial: D868
|
| 14. |
140124
|
[1] |
SHIM,40mm ID x 50mm OD x 0.5mm Thk
|
ZED
, Serial Range: -C867
|
| 14. |
84293745
|
[1] |
ADJUSTING PLATE
|
ZED
0.5 mm Thk, Start Serial: D868
|
| 15. |
440978
|
[1] |
WASHER,40mm ID x 50mm OD x 0.2mm Thk
|
ZED
, Serial Range: -C867
|
| 15. |
84293746
|
[1] |
ADJUSTING PLATE
|
ZED
0.2 mm Thk, Start Serial: D868
|
| 16. |
87490146
|
[1] |
ADJUSTING PLATE
|
ZED
0.15 mm Thk, Serial Range: -C867
|
| 16. |
84293747
|
[1] |
ADJUSTING PLATE
|
ZED
0.15 mm Thk, Start Serial: D868
|
| 17. |
375400
|
[1] |
SEALING RING
|
ZED
|
| 18. |
84062387
|
[1] |
RING,55mm ID x 90mm OD x 12.85mm L
|
ZED
|
| 19. |
9838835
|
[1] |
SHIM,57.15mm ID x 76.2mm OD x 0.25mm Thk
|
ZED
, Start Serial: D868
|
