纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-011-00[01]) - COUNTERWEIGHT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
453 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUB0191 | [1] | WEIGHT PACKAGE | SUM |
| 2. | 151156A1 | [2] | BOLT | SUMM42 x 800 Superseded by part number: KUB10300 |
| 3. | 163649A1 | [2] | BOLT,High Strength, Hex, M42 x 700mm | SUMM42 x 700 |
| 4. | 166UR042VN | [4] | NUT | SUMM42 Superseded by part number: KUB10970 |
| 5. | 150400A1 | [8] | WASHER | SUM Superseded by part number: KUB10960 |
| 6. | KUB0133 | [1] | COVER | SUM Superseded by part number: KUB0133Y2 |
| 7. | 152718A1 | [5] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 8. | KUB0028 | [1] | SEAL | SUM |
| 9. | KUB0075 | [2] | SEAL | SUM |
| 10. | 151020A1 | [1] | ADJUSTING PLATE | SUM2,00 mm (0,079 in) |
| 11. | 151023A1 | [1] | ADJUSTING PLATE | SUM3,20 mm (0,126 in) |
| 12. | 151028A1 | [1] | ADJUSTING PLATE | SUM4,50 mm (0,177 in) |
| 13. | KUB0110 | [1] | SHIM,2.3mm Thk | SUM |
| 14. | KUB0111 | [1] | SHIM,3.2mm Thk | SUM |
