纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-013-00[01]) - COWLING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
457 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUN0280 | [1] | FRAME | SUM |
| 2. | 152718A1 | [1] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 3. | KUN0285 | [1] | BRACKET | SUM |
| 4. | 627-12035 | [2] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 5. | 150811A1 | [2] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 6. | KUN0405 | [1] | CONSOLE | SUM |
| 9. | KUN0277 | [1] | FRAME | SUM |
| 13. | 159091A1 | [2] | STOP | SUM |
| 14. | 162R010VR | [2] | NUT | SUM Superseded by part number: 86500689 |
| 15. | KUN0289 | [1] | FRAME | SUM |
| 16. | 166352A1 | [4] | BOLT | SUM |
| 17. | KUN0278 | [1] | FRAME | SUM |
| 19. | KUN0286 | [1] | COVER | SUM |
| 20. | KUN0304 | [1] | COVER | SUM |
| 21. | KUN0287 | [1] | COVER | SUM |
| 22. | KUN0288 | [1] | COVER | SUM |
| 24. | 159656A1 | [1] | GROMMET | SUM |
| 25. | KUN0367 | [1] | GASKET | SUM |
| 33. | KUN0301 | [1] | COVER | SUM |
| 35. | KUN0279 | [1] | FRAME | SUM |
| 37. | KUN0276 | [1] | FRAME | SUM |
| 39. | KUN0284 | [1] | FRAME | SUM |
| 41. | KUN0290 | [1] | FRAME | SUM |
| 43. | KUN0283 | [1] | FRAME | SUM |
| 46. | KUN0402 | [1] | FRAME | SUM |
| 50. | KUN0355 | [1] | COVER | SUM |
| 52. | KUN0254 | [1] | WASHER | SUM |
| 53. | KUN0282 | [1] | FRAME | SUM |
| 77. | KUN0105 | [1] | SEAL, RUBBER | SUMRUBBER SEAL |
| 118. | KUN0317 | [1] | COVER | SUM |
| 120. | KUN0315 | [1] | COVER | SUM |
| 122. | KUN0316 | [1] | COVER | SUM |
| 124. | KUN0318 | [1] | COVER | SUM |
| 126. | KUN0319 | [1] | COVER | SUM |
| 128. | KUN0357 | [1] | COVER | SUM |
| 130. | KUN0358 | [1] | COVER | SUM |
| 132. | KUN0161B1 | [1] | STAY | SUM |
| 135. | KUN0264B1 | [1] | GRAB RAIL | SUM |
| 139. | KUN0263B1 | [1] | GRAB RAIL | SUM |
| 148. | KUN0327 | [1] | INSULATOR | SUM |
| 149. | KUN0328 | [1] | INSULATOR | SUM |
| 150. | KUN0329 | [1] | INSULATOR | SUM |
| 151. | KUN0330 | [1] | INSULATOR | SUM |
| 152. | KUN0331 | [1] | INSULATOR | SUM |
| 153. | KUN0332 | [1] | INSULATOR | SUM |
| 154. | KUN0333 | [1] | INSULATOR | SUM |
| 155. | KUN0334 | [1] | INSULATOR | SUM |
| 156. | KUN0335 | [1] | INSULATOR | SUM |
| 157. | KUN0336 | [1] | INSULATOR | SUM |
| 252. | KUN0238 | [1] | INSPECTION DOOR | SUM |
| 253. | 151104A1 | [2] | HINGE | SUM |
| 254. | 150939A1 | [1] | LOCK | SUM Superseded by part number: 150938A1 |
| 264. | KUN0239 | [1] | INSPECTION DOOR | SUM |
| 266. | 150938A1 | [1] | LOCK | SUM |
