神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-043) - COVER ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
559 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21C01114F1 | [1] | COVER ASSY | KOB |
| 1. | YX21C01063P1 | [1] | COVER | KOB |
| 2. | YY21C01112P2 | [1] | SUPPORT | KOB Superseded by part number: YY21C01659P1 |
| 2-8. | YT21C01225P1 | [2] | HINGE | KOB |
| 3. | YT21C01034P2 | [1] | CATCH | KOB |
| 5. | YX21C01159F1 | [1] | LOCK | KOBASSY |
| 5-1. | YR22C01025P1 | [1] | LOCK | KOB, Serial Range: YH02-01301-YH02-02096 Superseded by part number: YR22C01025P2 |
| 5-1. | YR22C01025P2 | [1] | LOCK | KOB, Start Serial: YH03-02097- |
| 5-2. | YX21C01188P1 | [1] | PLATE | KOB |
| 6. | ZS18C10020 | [6] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 7. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 8. | HY25X10027G1 | [6] | WASHER,10mm ID x 27mm OD x 3.2mm Thk | KOBID 10 x OD 27 x Th 3.2mm |
| 9. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm, Serial Range: YH02-01301-YH02-01335 |
| 9. | ZS18C06018 | [2] | SCREW,Hex, M6 x 18mm | KOBM06x1.0x18mm, Start Serial: YH02-01336- |
| 10. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 11. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 12. | YY21C01132P1 | [1] | ROD | KOB |
| 13. | YT21C01107P1 | [1] | BRACKET | KOB |
| 14. | YT21C01155P1 | [1] | WASHER | KOB |
| 15. | YT21C01053P1 | [2] | CLIP | KOB |
| 16. | YT21C01324P1 | [1] | COVER | KOBCOVER |
| 17. | YY21C01167D1 | [4] | RUBBER | KOBRUBBER |
