| 1. |
84807838
|
[1] |
LEVER
|
ZED
|
| 2. |
370007
|
[6] |
SNAP RING,M45, Ext
|
NH
|
| 3. |
84068193
|
[1] |
LEVER
|
ZED
|
| 4. |
87362339
|
[3] |
SHAFT
|
ZED
|
| 5. |
86508450
|
[1] |
BALL
|
ZED
Superseded by part number: D9NN557AA
|
| 6. |
84078757
|
[1] |
SENSOR
|
ZED
60 kN, B17 - LOAD SENSOR, Serial Range: -C813 Superseded by part number: 84523156
|
| 6. |
84232219
|
[1] |
SENSOR
|
ZED
, Serial Range: -F814923 Superseded by part number: 84523156
|
| 6. |
84523156
|
[1] |
SENSOR
|
ZED
, Start Serial: D924
|
| 6. |
84074551
|
[1] |
SENSOR
|
ZED
90 kN, B17 - LOAD SENSOR, Serial Range: -C813 Superseded by part number: 84523153
|
| 6. |
84232218
|
[1] |
SENSOR
|
ZED
, Serial Range: -F814923 Superseded by part number: 84523153
|
| 6. |
84523153
|
[1] |
SENSOR
|
ZED
, Start Serial: D924
|
| 7. |
43127
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 8. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 9. |
84062747
|
[1] |
BOLT,Hex, M30 x 150mm, Cl 8.8, Full Thd
|
ZED
, Serial Range: -C799 Superseded by part number: 84801382
|
| 9. |
87610711
|
[1] |
BOLT,Hex, M24 x 160mm, Cl 10.9
|
BRR
, Serial Range: -F800813
|
| 9. |
86639186
|
[1] |
SCREW,Hex, M24 x 140mm, Cl 10.9
|
FAR
, Start Serial: D814
|
| 9. |
84801382
|
[1] |
BOLT
|
ZED
M30 x 150, Serial Range: -C799
|
| 10. |
84062741
|
[1] |
DISC,31mm ID x 56mm OD x 11.2mm W
|
ZED
, Serial Range: -C799
|
| 11. |
84062740
|
[1] |
DISC
|
ZED
, Serial Range: -C799
|
| 12. |
84062746
|
[1] |
THIN NUT,Thin, M30 x 3.5, Cl 05
|
ZED
, Serial Range: -C799
|
| 12. |
85700123
|
[1] |
NUT,M24, Cl 8
|
BER
, Start Serial: D800 Superseded by part number: 57139
|
| 13. |
84068192
|
[1] |
ARM
|
ZED
, Serial Range: -C799
|
| 13. |
84185669
|
[1] |
ADJUSTER
|
ZED
, Start Serial: D800
|
| 14. |
84607479
|
[1] |
CLAMP
|
ZED
|
| 15. |
87673373
|
[1] |
THRUST BEARING,25mm ID x 62mm OD x 22.5mm W
|
ZED
, Start Serial: D800
|
| 16. |
87677406
|
[1] |
PROTECTING COVER
|
ZED
, Start Serial: D800
|
| 17. |
43128
|
[1] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
, Start Serial: D800
|
| 19. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
, Start Serial: D800 Superseded by part number: 43362
|
