纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-047-00[01]) - HAND CONTROL ARM - LEFT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
834 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 33. | KHJ1641 | [4] | BOLT,Hex Skt Hd | SUM |
| 33A. | 140028 | [4] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NH |
| 33B. | 895-11010 | [4] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
| 61. | KHN2247 | [1] | PADDING | SUM |
| 62. | KHN2270 | [2] | LOCKING RING | SUM |
| 63. | KHN2249 | [2] | BUSHING | SUM |
| 64. | KHN2263 | [1] | SPRING | SUM |
| 65. | KHN2250 | [1] | PIN | SUM |
| 66. | KHN2253 | [1] | TRIGGER | SUM |
| 66A. | KHN2251 | [1] | BUSHING | SUM |
| 67. | KHN2276 | [1] | THREADED ROD | SUM |
| 68. | 829-1406 | [2] | NUT,Hex, M6 x 1, Cl 10.9 | CAS Superseded by part number: 86500688, 87778396 |
| 69. | 892-11006 | [1] | LOCK WASHER,M6 | CAS Superseded by part number: 86517328 |
| 70. | 150054A1 | [1] | BALL JOINT | SUM |
| 71. | KHN2260 | [1] | THREADED ROD | SUM |
| 72. | 330-016S008R | [1] | SPLIT PIN/SAFETY PIN | SUM |
| 73. | KHN2258 | [1] | LINK | SUM |
| 74. | 159091A1 | [1] | STOP | SUM |
| 75. | 829-1410 | [1] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 76. | KHN2277 | [1] | SPRING | SUM |
| 77. | KHN2245 | [1] | FRAME | SUM |
| 78. | KHN2266 | [1] | PIN | SUM |
| 79. | KHN2397 | [1] | LOCKING RING | SUM |
| 80. | KHN2264 | [1] | PIN | SUM |
| 81. | KHN2268 | [1] | BUSHING | SUM |
| 82. | KHN2262 | [1] | BUSHING | SUM |
| 83. | KHN2269 | [1] | LOCKING RING | SUM |
| 84. | KHN2279 | [1] | BUSHING | SUM |
| 85. | 896-11016 | [1] | WASHER,17.5mm ID x 30mm OD x 4mm Thk | IH Superseded by part number: 86625266 |
| 86. | 157560A1 | [1] | WAVE WASHER | SUM |
| 87. | 627-8016 | [1] | BOLT,Hex, M8 x 1.25 x 16mm, Cl 10.9, Full Thd | CAS Superseded by part number: 16043231 |
| 88. | 87016617 | [1] | LOCK WASHER,M8 | RAC Superseded by part number: 83990583 |
| 89. | 895-11008 | [1] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
| 90. | 378J0050Z | [2] | CIRCLIP | SUM |
| 91. | 895-11006 | [3] | WASHER,M6 x 12mm OD x 1.6mm | CAS Superseded by part number: 86588450 |
| 92. | KHN2259 | [1] | PIN | SUM |
| 93. | KHN2272 | [2] | LOCKING RING | SUM |
| 94. | KHN2261 | [2] | BUSHING | SUM |
| 95. | KHN2401 | [1] | SPACER | SUM |
| 96. | KHN2257 | [1] | LINK | SUM |
| 97. | KHN2267 | [1] | BAR | SUM |
| 98. | 829-1408 | [1] | NUT,Hex, M8 x 1.25, Cl 10.9 | CAS Superseded by part number: 43362, 87778059 |
| 99. | 627-8020 | [1] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43233 |
| 99A. | 733-1616 | [1] | COTTER PIN,M1.6 x 16 | CAS Superseded by part number: 87016658 |
| 104. | 166459A1 | [1] | LIMIT SWITCH | SUM |
| 106. | KHN2254 | [1] | SUPPORT | SUM |
| 107. | KHN3243 | [1] | LEVER | SUM |
| 108. | KHN2256 | [1] | SUPPORT | SUM |
| 109. | KHN2339 | [1] | BUSHING | SUM |
| 113. | KHN2337 | [1] | SEAL | SUM |
| 114. | KHN2278 | [1] | SPRING | SUM |
| 115. | 166350A1 | [1] | BOLT | SUM |
| 116. | KHN2366 | [1] | STOP | SUM |
| 117. | KHN2132 | [1] | BOLT,Hex Flg Hd, M6 x 16 | SUM |
| 118. | KHN2283 | [1] | LEVER | SUM |
| 119. | 862-8025 | [1] | HEX SOC SCREW,M8 x 25mm, Cl 12.9 | CASM8 x 25; 12.9 |
| 140. | KHN2287 | [1] | COVER | SUM |
| 141. | KHN3010 | [1] | COVER | SUM |
| 142. | KHN3579 | [1] | COVER | SUM |
| 143. | KHN2558 | [1] | SEAL | SUM |
| 144. | KHN3574 | [1] | CONSOLE | SUM |
| 146. | KHN2367 | [2] | BOLT | SUM |
| 147. | KHN2058 | [1] | ASH TRAY | SUM |
| 148. | KHN2336 | [1] | HOUSING | SUM |
| 149. | KHN2895 | [1] | CUP COVER | SUM |
| 150. | KHN2022 | [1] | BELLOWS | SUM |
| 151. | KHN2282 | [1] | BRACKET, SUPPORTING | SUM |
| 152. | KHN2131 | [2] | BOLT | SUM |
| 153. | KHN3011 | [1] | COVER | SUM |
