纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-045-00[01]) - OPERATORS COMPARTMENT - SEAT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
664 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 31. | KHN3586 | [1] | COVER | SUM |
| 32. | KHN2132 | [1] | BOLT,Hex Flg Hd, M6 x 16 | SUM |
| 35. | KHN2823 | [1] | HOLDER | SUM |
| 36. | KHN2473 | [1] | SLIDE GUIDE | SUM |
| 37. | KHN2474 | [1] | SLIDE GUIDE | SUM |
| 38. | KHN2475 | [1] | CENTRAL RAIL | SUM |
| 39. | KHN2476 | [1] | CENTRAL RAIL | SUM |
| 40. | 162R010VR | [8] | NUT | SUMM10; 10 Superseded by part number: 86500689 |
| 41. | 140028 | [8] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NH |
| 76. | 166346A1 | [8] | BOLT,Sems, M10 | SUM |
| 155. | KHN11990 | [1] | DRIVER SEAT | SUM Superseded by part number: KHN12810 |
