纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-059-00[01]) - CAB AND GLASS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
566 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | KHN11950 | [1] | CAB | SUM |
| 4. | KHN3662 | [1] | CAB BODY | SUM |
| 5. | 161384A1 | [1] | RH DOOR LOCK | SUM |
| 6. | 161380A1 | [1] | CABLE | SUM |
| 7. | 161381A1 | [4] | COLLAR | SUM |
| 8. | KHN3026 | [1] | SEAL | SUM Superseded by part number: 161385A1 |
| 11. | 161376A1 | [1] | LEVER | SUM |
| 12. | 161375A1 | [1] | HANDLE | SUM |
| 13. | 161358A1 | [1] | COAT HOOK | SUM |
| 14. | 161373A1 | [1] | GROMMET | SUM |
| 16. | 161383A1 | [1] | GROMMET | SUM |
| 20. | 161378A1 | [1] | COVER | SUM |
| 21. | KHN2636 | [1] | CAB GLASS | SUM |
| 22. | KHN2637 | [1] | WEATHERSTRIP | SUM |
| 23. | KHN2638 | [1] | CAB GLASS | SUM |
| 24. | KHN2639 | [1] | WEATHERSTRIP | SUM |
| 25. | KHN2640 | [1] | CAB GLASS | SUM |
| 26. | KHN2641 | [1] | WEATHERSTRIP | SUM |
| 27. | KHN2642 | [1] | CAB GLASS | SUM |
| 28. | KHN2643 | [1] | SEAL | SUMSEAL,WINDOW |
| 30. | KHN2655 | [1] | WEATHERSTRIP,4508mm L | SUM |
| 33. | KHN2658 | [5] | SEAL | SUM |
| 48. | KHN2670 | [1] | RETAINER | SUM Superseded by part number: KHN11680 |
| 49. | KHN2671 | [2] | SCREW | SUMM6 x 1 x 20 |
| 50. | KHN2672 | [1] | RETAINER | SUM Superseded by part number: KHN11690 |
| 53. | KHN2676 | [1] | STOP | SUM |
| 57. | KHN2680 | [1] | LATCH HOOK | SUM |
| 58. | KHN2681 | [4] | SCREW | SUMM6 x 1 x 30 |
| 59. | KHN2682 | [1] | SCREW,Spcl | SUMM6 x 1 x 12 |
| 60. | KHN2683 | [1] | HOLDER | SUM |
| 61. | KHN2684 | [1] | STOP | SUM |
| 62. | KHN2686 | [5] | BOLT,Spcl | SUMM6 x 1 x 20 Superseded by part number: KHN18890 |
| 63. | KHN2687 | [4] | SCREW,Spcl | SUMM5 x 14 |
| 64. | KHN2688 | [12] | BOLT,Spcl | SUMM8 x 25 Superseded by part number: KHN18920 |
| 65. | KHN2689 | [1] | PROTECTOR | SUM |
| 66. | KHN2690 | [1] | PROTECTOR | SUM |
| 67. | KHN2691 | [13] | ANCHOR | SUM |
| 73. | KHN3641 | [1] | TRIM PANEL | SUM |
| 74. | KHN2292 | [3] | COLLAR | SUM |
| 75. | KHR4278 | [1] | DUCT | SUM |
| 76. | KHR4276 | [1] | DUCT | SUM |
| 77. | KHR2739 | [6] | SELF-TAP SCREW | SUM Superseded by part number: KHR3016 |
| 79. | KHN3621 | [1] | TRIM PANEL | SUM |
| 80. | KHR4279 | [1] | DUCT | SUM |
| 81. | KHR4277 | [1] | DUCT | SUM |
| 83. | KHN2700 | [12] | BOLT,Spcl | SUMM6 x 16 |
| 87. | KHN2704 | [2] | STOP | SUM |
| 106. | KHN2722 | [1] | LEDGER PLATE | SUM |
| 107. | KHN2723 | [1] | CAP ASSY. | SUM |
| 108. | KHN2724 | [1] | BRACKET | SUM |
| 109. | KHN2725 | [1] | SUPPORT | SUM |
| 112. | KHN2729 | [1] | SEAL | SUM |
| 151. | KHN2982 | [2] | PAD, RUBBER | SUM |
| 259. | KHN2234 | [1] | TRIM PANEL | SUM |
| 261. | KHN3633 | [1] | PADDING | SUM |
| 262. | KHN2293 | [3] | COLLAR | SUM |
| 264. | KHN3636 | [1] | BOX | SUM |
| 265. | KHN3022 | [3] | SCREW | SUM |
| 266. | KHN2294 | [1] | SEAL | SUM |
| 272. | KHN2316 | [1] | BOLT | SUM |
| 273. | 150529A1 | [1] | WASHER | SUM |
| 281. | KHN2974 | [1] | BRACKET | SUM |
| 282. | KHN2975 | [1] | SCREW,Spcl | SUM |
| 283. | KHN2947 | [6] | PLUG | SUM |
