纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-063-00[01]) - CAB - WINDSHIELD - OPENING ROOF New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
307 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 9. | 161353A1 | [1] | SHIM | SUM |
| 10. | 161352A1 | [1] | STOP | SUM |
| 17. | 159584A1 | [1] | FLANGE BOLT,Shldr | SUM |
| 29. | KHN2654 | [2] | RUBBER BLOCK | SUM |
| 31. | KHN3259 | [1] | ROOF LINING | SUM |
| 32. | KHN2657 | [1] | CATCH PLATE | SUM |
| 33. | KHN2658 | [7] | SEAL | SUM |
| 34. | KHN2896 | [10] | BOLT,Spcl | SUMM6 x 1 x 16 |
| 35. | KHN2971 | [1] | BAR | SUM |
| 36. | KHN2661 | [2] | RUBBER BLOCK | SUM |
| 37. | KHN2662 | [1] | WEATHERSTRIP | SUM |
| 39. | KHN2664 | [1] | SUPPORT | SUM |
| 40. | KHN2665 | [1] | BOLT,Spcl | SUMM6 x 1 x 10 |
| 41. | KHN2666 | [1] | SPRING | SUM |
| 42. | 161453A1 | [1] | FLANGE NUT | SUM |
| 44. | KHN2668 | [1] | SUPPORT | SUM |
| 46. | KHN2669 | [1] | SPRING | SUM |
| 49. | KHN2671 | [10] | SCREW | SUMM6 x 1 x 20 |
| 51. | KHN2673 | [2] | STOP | SUM |
| 52. | KHN2674 | [2] | LOCKING TAB | SUM |
| 68. | KHN2692 | [1] | GUIDE | SUM |
| 69. | KHN2693 | [1] | GUIDE | SUM |
| 70. | KHN2694 | [6] | SCREW,Spcl | SUMM5 x 16 |
| 126. | KHN2750 | [1] | LOCK ASSY | SUM |
| 127. | KHN2751 | [2] | SCREW,Spcl | SUMM8 x 16 |
| 128. | KHN2752 | [1] | CATCH PLATE | SUM |
| 152. | KHN2850 | [1] | BOLT,Spcl | SUMM10 x 25 |
| 157. | KHN2881 | [1] | SEAL PROTECTION | SUM |
| 158. | KHN2908 | [2] | WASHER | SUM |
| 219. | KHN3671 | [1] | HATCH | SUM |
| 220. | 161451A1 | [1] | LATCH ASSY. | SUM |
| 221. | KHN3258 | [1] | ROOF LINING | SUM |
| 222. | KHN2824 | [4] | SPACER | SUM |
| 223. | KHN2825 | [4] | ANCHOR | SUMFIXATION |
| 224. | KHN2682 | [4] | SCREW,Spcl | SUMM6 x 1 x 12 |
| 224A. | KHN3331 | [4] | SCREW,Spcl | SUM |
| 225. | KHN2827 | [2] | GAS STRUT | SUM |
| 226. | KHN2828 | [4] | CIRCLIP | SUM |
| 227. | KHN2909 | [2] | HINGE | SUM |
| 230. | KHN3622 | [1] | WINDOW ASSY | SUM |
| 231. | KHN2857 | [1] | WINDOW FRAME | SUM |
| 233. | 161410A1 | [3] | HANDLE | SUM |
| 234. | 161436A1 | [1] | SPRING | SUM |
| 235. | 161411A1 | [6] | SCREW | SUM |
| 236. | KHN2632 | [1] | WINDSHIELD | SUM |
| 237. | KHN2633 | [1] | WEATHERSTRIP | SUM |
| 238. | KHN2686 | [4] | BOLT,Spcl | SUMM6 x 1 x 20 Superseded by part number: KHN18890 |
| 239. | KHN2702 | [2] | SCREW,Spcl | SUMM8 x 20 |
| 241. | KHN2830 | [1] | LATCH ASSY. | SUM |
| 242. | KHN2831 | [1] | LEVER | SUM |
| 243. | KHN2832 | [1] | STRIKER PLATE | SUM |
| 244. | KHN2833 | [2] | SUPPORT | SUM |
| 244A. | KHN3024 | [2] | SHIELD | SUM |
| 245. | KHN2834 | [4] | ROLLER BEARING | SUM |
| 246. | KHN2835 | [1] | PIN | SUM |
| 247. | KHN2836 | [1] | LEVER | SUM |
| 248. | KHN2837 | [1] | GASKET | SUM |
| 249. | KHN2838 | [1] | SEAL | SUM |
| 250. | KHN3623 | [1] | PADDING | SUM |
| 251. | KHN2840 | [4] | FASTENER | SUM |
| 252. | KHN2617 | [1] | WINDOW ASSY | SUM Superseded by part number: KHN2842, KHN2762, KHN2841, KHN2764, KHN2634, KHN2761 |
| 253. | KHN2634 | [1] | CAB GLASS | SUM |
| 254. | KHN2761 | [4] | NUT | SUM |
| 255. | KHN2762 | [4] | GROMMET | SUM |
| 256. | KHN2764 | [4] | SCREW,Spcl | SUMM5 x 0,8 x 10 |
| 257. | KHN2841 | [1] | SEAL | SUM |
| 258. | KHN2842 | [1] | SEAL | SUM |
| 267. | 166352A1 | [5] | BOLT | SUM |
| 268. | 627-12040 | [2] | BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 337563 |
| 269. | ADS2876 | [2] | BOLT | SUMM12 x 50 |
| 270. | 162R012VR | [2] | NUT | SUMM12 |
| 271. | 150811A1 | [6] | WASHER | SUMM12 Superseded by part number: 86625255 |
