纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-093-00[01]) - AIR CONDITIONING - EVAPORATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
695 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | KHR4135 | [1] | AIR CONDITIONER | SUM |
| 3. | KHR2802 | [1] | MOTOR, ELECTRIC | SUM |
| 40. | KHR4118 | [1] | RESISTOR | SUM |
| 41. | KHR2841 | [1] | HOUSING | SUM |
| 42. | KHR2842 | [1] | HOUSING | SUM |
| 43. | KHR2843 | [1] | BRACKET | SUM |
| 44. | KHR2844 | [1] | HOSE | SUM |
| 45. | KHR2845 | [1] | MOTOR, ELECTRIC | SUM |
| 46. | KHR2846 | [1] | HOUSING | SUM |
| 47. | KHR2847 | [1] | HOUSING | SUM |
| 48. | KHR2848 | [1] | FILTER | SUM Superseded by part number: 47716914 |
| 49. | KHR2849 | [1] | LEVER | SUM |
| 50. | KHR2850 | [1] | LEVER | SUM |
| 51. | KHR2851 | [1] | SHUTTER | SUM |
| 52. | KHR2852 | [1] | GASKET | SUM |
| 53. | KHR2855 | [2] | SCREW | SUM |
| 54. | KHR2856 | [10] | SCREW | SUM |
| 55. | KHR2857 | [11] | SELF-TAP SCREW | SUM |
| 56. | KHR2858 | [3] | SCREW | SUM |
| 57. | KHR2859 | [3] | SELF-TAP SCREW | SUM |
| 58. | KHR2860 | [1] | BRACKET | SUM |
| 64. | KHR2771 | [1] | DUCT | SUM |
| 65. | KHR2773 | [2] | COLLAR | SUM |
| 66. | KHR2761 | [1] | DUCT | SUM |
