纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-089-00[01]) - CAB AIR CONDITIONING - AIR CONDITIONER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
844 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | KHR4135 | [1] | AIR CONDITIONER | SUM |
| 3. | KHR2802 | [2] | MOTOR, ELECTRIC | SUM |
| 4. | KHR2803 | [1] | VALVE | SUM |
| 5. | KHR2804 | [1] | SENSOR | SUM |
| 6. | KHR2805 | [2] | CLAMP | SUM |
| 7. | KHR2806 | [2] | HOLDER | SUM |
| 8. | KHR2807 | [1] | HOLDER | SUM |
| 9. | KHR2808 | [1] | CLAMP | SUM |
| 10. | KHR4115 | [1] | COOLER | SUM |
| 11. | KHR2810 | [1] | HOUSING | SUM |
| 12. | KHR2811 | [1] | HOUSING | SUM |
| 13. | KHR2812 | [1] | HOUSING | SUM |
| 14. | KHR4116 | [1] | OUTER SHIELD | SUM |
| 15. | KHR4117 | [1] | OUTER SHIELD | SUM |
| 16. | KHR2815 | [2] | STRIP-GASKET | SUM |
| 17. | KHR2816 | [1] | STRIP-GASKET | SUM |
| 18. | KHR11400 | [1] | CONSOLE | SUM |
| 19. | KHR2818 | [1] | CLAMP | SUM |
| 20. | KHR2819 | [2] | LEVER | SUM |
| 21. | KHR2820 | [1] | LEVER | SUM |
| 22. | KHR2821 | [1] | LEVER | SUM |
| 23. | KHR2822 | [4] | LEVER | SUM |
| 24. | KHR2823 | [4] | LEVER | SUM |
| 25. | KHR2824 | [1] | CAM | SUM |
| 26. | KHR2825 | [1] | THREADED ROD | SUM |
| 27. | KHR2826 | [1] | THREADED ROD | SUM |
| 28. | KHR2827 | [1] | THREADED ROD | SUM |
| 29. | KHR2828 | [1] | SHUTTER | SUM |
| 30. | KHR2829 | [1] | SHUTTER | SUM |
| 31. | KHR2830 | [1] | SHUTTER | SUM |
| 32. | KHR2831 | [1] | SHUTTER | SUM |
| 33. | KHR2832 | [1] | SHUTTER | SUM |
| 34. | KHR2833 | [1] | SHUTTER | SUM |
| 35. | KHR11390 | [1] | RADIATOR, HEATER | SUM |
| 36. | KHR2835 | [1] | ECU | SUM |
| 37. | KHR2836 | [1] | RELAY | SUM |
| 38. | KHR2838 | [3] | MOUNTING CLIP | SUM |
| 39. | KHR2839 | [1] | HARNESS | SUM |
| 53. | KHR2855 | [4] | SCREW | SUM |
| 54. | KHR2856 | [3] | SCREW | SUM |
| 55. | KHR2857 | [20] | SELF-TAP SCREW | SUM |
| 57. | KHR2859 | [6] | SELF-TAP SCREW | SUM |
| 59. | KHR2861 | [2] | BOLT,Hex Skt Hd | SUM |
| 60. | KHR2862 | [5] | SELF-TAP SCREW | SUM |
| 61. | KHR2837 | [1] | PACKING | SUM |
| 62. | KHR2853 | [1] | CAP | SUM |
| 63. | KHR2854 | [1] | CLAMP | SUM |
| 66.1. | 169053A1 | [1] | O-RING | CAS |
| 66.2. | 169054A1 | [1] | O-RING | CAS |
