神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-013) - WATER PUMP AND CORROSION RESISTER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONWATER PUMP AND CORROSION RESISTOR |
| 1(B). | VI8972530281 | [1] | WATER PUMP | KOBASM, W/GASKET Superseded by part number: 288878A1 |
| 3. | VI8943706610 | [1] | GASKET | KOBPUMP TO C/BL |
| 4(B). | VI5878143200 | [1] | REPAIR KIT, WATER PUMP | |
| 7(B). | VI1136411650 | [1] | PULLEY | KOBWATER PUMP (2-GROOVE) |
| 9. | VI9091801520 | [1] | RING, SNAP, WATER PUMP | |
| 11. | VI5136340020 | [1] | SPACER, BRG, WATER PUMP | |
| 16. | VI5096250550 | [1] | SEAL, OIL, WATER PUMP | |
| 18. | VI8972322500 | [1] | IMPELLER, WATER PUMP | |
| 19. | VI8972322480 | [1] | GASKET | SMGASKET, COVER TO BODY Superseded by part number: 72109964 |
| 20. | VI8972322470 | [1] | COVER, WATER PUMP | |
| 25. | VI5136420072 | [1] | CENTER JOINT | KOBWATER PUMP |
| 26. | VI5136390010 | [1] | COVER, DUST, WATER PUMP | |
| 27(A). | VI5098000510 | [1] | BEARING | KOBWATER PUMP |
| 27(B). | VI5098000500 | [1] | BEARING | KOBWATER PUMP |
| 27(C). | VI1098001700 | [1] | BEARING, WATER PUMP | |
| 28. | VI1095030700 | [1] | WASHER, WATER PUMP | |
| 29. | VI1136310740 | [1] | SHAFT, WATER PUMP | |
| 30. | VI9099521430 | [1] | RING, SNAP, WATER PUMP SHAFT | |
| 31. | VI8972498951 | [1] | PIPE, SUCTION, INL | |
| 32. | VI8972322490 | [1] | SEAL | KOBUNIT, WATER PUMP Superseded by part number: VI1136200230 |
| 34. | VI9030908200 | [3] | SCREW | KOBCOVER TO BODY, WATER PUMP |
| 36. | VI0280810350 | [1] | BOLT, WATER PUMP TO C/BL (M10X35 FLANGE) | |
| 36. | VI0280810450 | [2] | BOLT, WATER PUMP TO C/BL (M10X45 FLANGE) | |
| 36. | VI0280810700 | [1] | BOLT, WATER PUMP TO C/BL (M10X70 FLANGE) | |
