神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-021) - FUEL PUMP AND PIPE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
660 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONFUEL PUMP AND PIPE |
| 107(A). | VI8972045160 | [1] | PIPE | KOBFUEL, FEED PUMP TO FUEL FILTER |
| 119(A). | VI8972045170 | [1] | PIPE | KOBFUEL, FUEL FILTER TO INJ PUMP |
| 158(A). | VI5154190040 | [1] | CLIP | KOBINJ PIPE TO INL MANIF |
| 158(B). | VI5154190051 | [1] | CLIP | KOBINJ PIPE TO INL MANIF |
| 159. | VI0286806160 | [1] | BOLT, CLIP | |
| 212. | VI8972254470 | [1] | VALVE | KOBOVERFLOW Superseded by part number: 288836A1 |
| 217. | VI1096300850 | [1] | GASKET | KOBOVERFLOW VLV |
