神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-001[00]) - BOOM INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
817 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02B00267F1 | [1] | | |
| 1. | YY02B01590P1 | [1] | PIN | KOB |
| 2. | YX02B01003P2 | [1] | PIN | KOB |
| 3. | YX02B01024P1 | [1] | SPRING | KOB |
| 4. | B16T0442D57 | [1] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOB0.5 |
| 5. | B16T0442D44 | [1] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOB0.9 |
| 6. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOB1.6 |
| 7. | B16T0442D5 | [1] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOB2.3 |
| 8. | YN12B01602D1 | [2] | SHIM,72mm ID x 130mm OD x 2mm Thk | KOB2.0 |
