神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-002[00]) - BOOM, HOE 4.68M Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
173 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02B00361F1 | [1] | Hoe 4.68M | |
| 1. | YY02B00362F1 | [1] | BOOM | KOBHoe |
| 2. | YY02B00238F1 | [1] | BOOM | KOBHoe |
| 3. | YY02B00219P1 | [1] | Hoe | |
| 4. | YY12B01449P1 | [2] | BUSHING | KOB |
| 5. | YY02B00363P1 | [1] | Hoe | |
| 6. | YN02B01619P1 | [2] | BLOCK,M12 Thd Hole - 75mm L x 41mm W | KOBTapped |
| 7. | YN02B01622P1 | [2] | BLOCK,M12 Thd Hole - 25mm Thk x 75mm W x 125mm L | KOBTapped |
| 8. | YY02B01313P1 | [2] | BRACKET | KOB |
| 9. | 2416T9878 | [1] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOBTapped |
| 10. | 2416T12922 | [2] | BLOCK | KOBTapped |
| 11. | YY02B01702P1 | [1] | BRACKET, SUPPORTING | KOB |
| 12. | 2418T22409 | [1] | PLATE | KOB |
| 13. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust |
