神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-008[01]) - HYDRAULIC LINES, BOOM (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
402 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY42H00303F1 | [1] | Boom, Nibbler & Breaker | |
| 1. | YY42H00342F1 | [1] | Boom | |
| 2. | YY42H02056P1 | [1] | PIPE | KOB |
| 3. | YY42H02057P1 | [1] | PIPE | KOB |
| 4. | YY42H02058P1 | [1] | PIPE | KOB |
| 5. | YY42H02059P1 | [1] | PIPE | KOB |
| 6. | YY42H01475P1 | [4] | CLAMP | KOB |
| 7. | YY42H01477P1 | [4] | CLAMP | KOB |
| 8. | YN42H02349P1 | [4] | CLAMP | KOB |
| 9. | YY42H01473P1 | [6] | BUSHING,21.7mm ID x 28mm OD x 83mm L | KOB |
| 10. | YN42H02319P1 | [2] | BUSHING,27.2mm ID x 34mm OD x 83mm L | SM Superseded by part number: 84354627 |
| 11. | ZD12A01600 | [6] | O-RING | KOB |
| 12. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 13. | ZM73C12035 | [10] | BOLT,M12x35mm - Course Thread | KOBSems |
