神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-011[01]) - BOOM CYLINDER INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
952 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02B00189F1 | [1] | | |
| 1. | YY02B01174P1 | [2] | PIN | KOB Superseded by part number: YY02B01174P2 |
| 2. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap M10x1.50x20mm |
| 3. | 2418T21137 | [2] | WASHER | KOB |
| 4. | ZW16H10000 | [2] | WASHER | KOB |
| 5. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOB1.6 |
| 6. | B16T0442D44 | [1] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOB0.9 |
| 7. | B16T0442D57 | [1] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOB0.5 |
| 8. | YN12B01602D1 | [4] | SHIM,72mm ID x 130mm OD x 2mm Thk | KOB2.0 |
| 9. | YY01V00053F3 | [2] | LIFT CYLINDER | KOBBoom Superseded by part number: YY01V00087F1 |
