神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-022[02]) - ARM INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
540 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY12B00237F1 | [1] | | |
| 2. | YY12B01922P1 | [1] | PIN | KOB |
| 3. | B16T0442D44 | [1] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOB0.9 |
| 4. | B16T0442D57 | [1] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOB0.5 |
| 5. | YN12B01602D1 | [2] | SHIM,72mm ID x 130mm OD x 2mm Thk | KOB2.0 |
| 6. | YY12B00250F1 | [1] | | |
| 7. | 2418T12645D2 | [1] | PLATE | KOB |
| 8. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBCap |
| 9. | ZW16H12000 | [2] | WASHER | KOB |
