神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-023[01]) - ARM GROUP 2.8M (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
636 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY12B00565F1 | [1] | Nibbler & Breaker | |
| 1. | YY12B01427P2 | [2] | PIN,68mm OD x 470mm L | KOB |
| 2. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 3. | YN12B01610D1 | [2] | SHIM | KOB2.0 |
| 4. | B16T0442D56 | [1] | SHIM,62mm ID x 100mm OD x 0.5mm Thk | KOB0.5 |
| 5. | B16T0442D43 | [1] | SHIM,62mm ID x 100mm OD x 0.9mm Thk | KOB0.9 |
| 6. | B16T0442D19 | [1] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOB1.6 |
