纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-032-02[01]) - ENGINE WATER CIRCUIT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
177 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 31A. | 419935A1 | [8] | BOLT | ISUM8 x 16 Superseded by part number: 76599954 |
| 31B. | 426275A1 | [1] | BOLT | ISUM10 x 16 Superseded by part number: 87597950 |
| 35A. | 87379738 | [10] | CLIP | ISUID 20 |
| 35B. | 87384808 | [6] | CLIP | ISUID 23 |
| 94A. | 87384810 | [2] | CLIP,19mm ID | ISUID 19 H 21 |
| 94B. | 76591845 | [1] | CLIP | ISUID 19 L 25 |
| 94C. | 87384811 | [4] | CLIP | ISUID 19 L 20 |
| 94D. | 87384812 | [1] | CLIP,19mm ID, P Type | ISUID 19 L 28 |
| 115A. | 87378567 | [2] | HOSE,6579.00 mm | ISU |
| 115C. | 87384832 | [1] | HOSE | ISU |
| 115D. | 87384833 | [1] | HOSE,30480.00 mm | ISU |
| 115E. | 87384834 | [1] | HOSE,800.00 mm | ISU |
| 115F. | 87384835 | [2] | HOSE,2469.00 mm | ISU |
| 206A. | 87384836 | [1] | PIPE | ISU |
| 206B. | 87384837 | [1] | PIPE | ISU |
| 206C. | 87384838 | [1] | PIPE | ISU |
| 206D. | 87384839 | [1] | PIPE | ISU |
