神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-024[00]) - ARM, LONG 2.84M (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
419 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY12B00378F1 | [1] | ARM | KOBLong 2.84M, Nibbler & Breaker |
| 1. | YY12B00379F1 | [1] | ARM | KOBLong |
| 2. | YY12B00300F1 | [1] | ARM | KOBLong |
| 3. | YY12B00296P1 | [1] | Long | |
| 4. | YY12B01446P1 | [2] | BUSHING,70mm ID x 115mm OD x 80mm L | KOB |
| 5. | YY12B01447P1 | [2] | BUSHING | KOB |
| 6. | YY12B01448P1 | [2] | BUSHING | KOB |
| 7. | YY12B01449P1 | [2] | BUSHING | KOB |
| 8. | YY12B00380P1 | [1] | Long | |
| 9. | YN43H01051P1 | [2] | BLOCK | KOBTapped |
| 10. | YY02B01184P1 | [4] | BLOCK | KOBTapped |
| 11. | YY12B00343P1 | [1] | Long | |
| 12. | YY12B01687P1 | [1] | PLATE | KOB |
| 13. | 2445R220D2 | [2] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust Superseded by part number: 84499663 |
| 14. | 2445R220D1 | [2] | SEAL,60mm ID x 75mm OD x 5mm Thk | KOBDust |
| 15. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust |
