神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-023[02]) - ARM GROUP 2.8M (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
573 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY12B01681F1 | [1] | LINKAGE YOKE | KOBBucket |
| 2. | YY12B01682P1 | [1] | Bucket | |
| 3. | YM12B01120P1 | [2] | BUSHING,65mm ID x 80mm OD x 69mm L | KOB |
| 4. | YB12B01101P1 | [2] | BUSHING,65mm ID x 80mm OD x 59mm L | KOB |
| 5. | YY12B01425P2 | [1] | LINK | KOB Superseded by part number: YY12B02191P1 |
| 6. | YY12B01426P1 | [1] | LINK CONROD | KOB |
| 7. | YY12B01428P3 | [1] | PIN | KOB |
| 8. | YY12B01429P3 | [1] | PIN | KOB Superseded by part number: YY12B02189P1 |
| 9. | HS18C14115G2 | [2] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOBCap |
| 10. | ZN18C14011 | [4] | NUT | KOB |
| 11. | 2445R220D2 | [6] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust Superseded by part number: 84499663 |
| 12. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 13. | YM12B01063D1 | [4] | SHIM,67mm ID x 110mm OD x 2mm Thk | KOB2.0 |
| 14. | 2418T4037D7 | [2] | SHIM,67mm ID x 110mm OD x 0.5mm Thk | KOB0.5 |
| 15. | 2418T4037D3 | [2] | SHIM,67mm ID x 110mm OD x 0.9mm Thk | KOB0.5 |
| 16. | 2418T4037D5 | [2] | SHIM,67mm ID x 110mm OD x 1.6mm thk | KOB1.6 |
