神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-029[00]) - HYDRAULIC LINES, ARM 2.84M (BUCKET) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
381 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY43H00117F1 | [1] | Arm 2.84M, Bucket | |
| 1. | YY43H01231D2 | [1] | FLEXIBLE HOSE | KOB |
| 2. | ZX60H10150 | [1] | FLEXIBLE HOSE | KOBAssy. |
| 3. | ZE13X12000 | [2] | CLAMP | KOBHalf |
| 4. | ZD12P02600 | [1] | O-RING | KOB |
| 5. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOB |
| 6. | ZW26K10000 | [4] | LOCK WASHER | KOBLock Superseded by part number: 12581679 |
