纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-050-01[01]) - OIL COOLER - ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
616 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 87379813 | [2] | ENGINE OIL FILTER | ISU Superseded by part number: 84206729 |
| 13. | 87386036 | [1] | PRESSURE RELIEF VALVE | ISU |
| 21A. | 288565A1 | [2] | GASKET | ISU Superseded by part number: 72110175 |
| 21B. | 76550083 | [1] | SEALING RING | SM Superseded by part number: 86987151 |
| 45. | 87386038 | [1] | MANIFOLD | ISU |
| 47. | 426458A1 | [1] | PACKING RING | ISU Superseded by part number: 72110441 |
| 100. | 289998A1 | [2] | PLUG | ISUM14 x 9 |
| 102. | 87544993 | [1] | OIL COOLER | ISU |
| 103A. | 426208A1 | [17] | BOLT | ISUM10 x 30 |
| 103B. | 426463A1 | [8] | BOLT | ISUM10 x 65 |
| 103C. | 426465A1 | [1] | BOLT | ISUM10 x 110 |
| 110. | 87386043 | [1] | HOUSING | ISU |
| 111. | 87386044 | [1] | COOLER | ISU |
| 114. | 426468A1 | [1] | PLATE | ISU |
| 115. | 87380183 | [4] | NUT | ISU |
| 175. | 426472A1 | [1] | GASKET,18.2mm ID x 24.4mm OD | ISUID 18.2 - OD 24.4 |
| 196. | 87386045 | [1] | THERMOSTAT | ISU |
| 197. | 426475A1 | [1] | GASKET | ISU Superseded by part number: 72110451 |
| 198. | 426476A1 | [1] | ELBOW | ISU |
| 199. | 289039A1 | [2] | BOLT | ISUM10 x 35 |
| 202. | 288856A1 | [1] | HOSE | SUM |
| 288. | 76557685 | [3] | PLUG | HIT Superseded by part number: 71455105 |
| 321. | 426494A1 | [2] | GASKET,312mm ID | ISUID 31.2 |
| 324. | 437852A1 | [4] | BOLT | ISUM10 x 80 |
| 352. | 87380141 | [2] | ADAPTER | ISU Superseded by part number: 72109795 |
| 380. | 426496A1 | [1] | FITTING | ISU |
| 444A. | 87386046 | [2] | GASKET | ISU |
| 444B. | 87386047 | [2] | GASKET | ISU |
| 462. | 426500A1 | [1] | MOUNTING CLIP | ISUID 14 |
| 469A. | 426413A1 | [2] | GASKET | ISUID 18.8 |
| 469C. | 446627A1 | [1] | GASKET | ISU |
| 496. | 87368654 | [1] | FILTER ASSY | ISU |
| 497. | 426504A1 | [1] | PIPE | ISU |
| 498. | 288993A1 | [1] | FLANGE BOLT | ISUM10 x 20 |
| 499A. | 426505A1 | [1] | COLLAR | ISU |
| 499B. | 426506A1 | [1] | RING | ISU |
| 502. | 426508A1 | [1] | COVER | ISU |
| 503. | 87386048 | [4] | BOLT | ISU |
| 506. | 87386050 | [10] | SCREW,M6 x 8mm | ISUM6 x 8 |
