纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-051-01[01]) - OILPUMP - STRAINER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
977 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87386051 | [1] | ENGINE OIL PUMP | ISU |
| 3. | 426501A1 | [1] | PIN, ROLL | ISUL 60 |
| 5. | 426624A1 | [1] | SPRING | ISU |
| 6. | 426625A1 | [1] | VALVE, PRESSURE RELI | ISUEF |
| 7A. | 426626A1 | [3] | BOLT | ISUM8 x 18 Superseded by part number: 72109564 |
| 7B. | 288635A1 | [1] | BOLT | ISUM10 x 60 Superseded by part number: 87601343 |
| 7C. | 87386054 | [2] | BOLT | ISUM8 x 35 |
| 11. | 426628A1 | [1] | COVER | ISU |
| 16. | 426629A1 | [1] | GASKET | ISU |
| 20A. | 426630A1 | [1] | PINION | ISU |
| 20B. | 87386055 | [1] | DRIVING GEAR | ISU |
| 29A. | 426199A1 | [1] | BOLT | ISUM10 x 85 |
| 29B. | 426632A1 | [2] | BOLT | ISUM10 x 107 |
| 29C. | 288575A1 | [1] | BOLT | ISUM10 x 80 |
| 41. | 426633A1 | [1] | BALL | ISU |
| 51. | 426636A2 | [1] | STRAINER ASSY. | ISU |
| 60. | 426637A1 | [1] | SUPPORT | ISU |
| 61. | 288993A1 | [6] | FLANGE BOLT | ISUM10 x 20 |
| 99. | 426638A1 | [1] | PLUG | ISU |
| 125. | 87386056 | [1] | COVER | ISU |
